"2S2/0-HEX-M" Double Wire Lug (2/0-14 AWG) & FLEX Wire (1/0-14 AWG)
In stock
SKU
2S2/0-HEX-M
$2.73
- Buy 160 for $2.03 each and save 26%
- Buy 500 for $1.52 each and save 44%
"2S2/0-HEX-M" 2/0-14 AWG wire range, and FLEX wire, 1/0-14 AWG, G-K including mm2 class 5, 2 barrel, aluminum or copper wire, CU9AL, 90C temperature rating, single 1/4" bolt (6mm) mounting hole, UL Listed, CSA Certified. 5mm Metric Hex Socket Screw. Made in the USA from domestic and imported parts.
Use of Ferrules (UL Listed) on 1/0-14 AWG
Convenient inspection window to visually inspect full conductor insertion
Made with 6061-T6 aluminum to provide maximum electrical contact and performance
Electro tin-plated, to warrant against corrosion
Plated aluminum or steel screw provides durable long lasting contact between the conductor and connector
 |
| For More Information Click the Icons Below | ||||||
 |
 |
 |
 |
 |
|
RoHS 10/10 |
| 2/0-3 AWG | 50 IN. LBS. |
| 4-6 AWG | 45 IN. LBS. |
| 8 AWG | 40 IN. LBS. |
| 10-14 AWG | 35 IN. LBS. |
|
1/0-1 AWG
|
75 IN. LBS.
|
|
1-4 AWG
|
55 IN. LBS.
|
|
4-8 AWG
|
50 IN. LBS.
|
| 8-10 AWG | 45 IN. LBS. |
| 10-14 AWG | 40 IN. LBS. |
| 175 Amp 75C Cu Wire |
| 195 Amp 90C Cu Wire |
| 135 Amp 75C Al Wire |
| 150 Amp 90C Al Wire |
| Per Wire in Power Distribution or Collection Mode |
| SKU | 2S2/0-HEX-M |
|---|---|
| Number of Wires | 2 Wires |
| Condition | New |
| AWG Wire Range | 2/0 - 14 AWG |
| FLEX Wire Range | 1/0-14 AWG |
| Screw Type | Hex Socket |
| CSA Canadian Standards Association Certified | Yes |
| UL | UL Listed (UL) |
| Meets RoHS | Yes |
