"B6A-NH-PCB-RS-NS" 6-14 AWG
6-14 AWG, 65 AMP, 1 leg at .336X.14” with a .10" (2.54mm) PCB penetration.Top screw entrance.
- Buy 725 for $0.41 each and save 27%
- Buy 5000 for $0.31 each and save 45%
- Buy 10000 for $0.28 each and save 50%
"B6A-NH-PCB-RS-NS" 6-14 AWG, 65 AMP, 1 leg at .336X.14” with a .10" (2.54mm) PCB penetration.Top screw entrance.
Zinc plated steel screw, and integrated aluminum foot, tin plated, solderable.
One piece Body THT Types
Wave and reflow solderable high current PCB wire terminal lug / connector for high amp power applications. THT (Through Hole Technology). Copper or aluminum wire, stranded and solid wire per UL486 wire code. Solid mass, high conductivity aluminum alloy body for tens of micro ohms range of resistance wire to foil conductivity, low resistance current path. Exceeds IEC volt drop test standards. Variety of wire binding screw options.
One piece SMT / SMD Solderable Body Types
Wave and reflow solderable high current PCB wire terminal lug / connector for high amp power applications. SMT / SMD (Surface Mount Technology, Surface Mount Device). View Soldering Temperature Profiles here. Copper or aluminum wire, stranded and solid wire per UL486 wire code. Solid mass, high conductivity aluminum alloy body for tens of micro ohms range of resistance wire to foil conductivity, low resistance current path. Exceeds IEC volt drop test standards. Variety of wire binding screw options.
Precuations when using SMT and SMT FAQ
| For More Information Click the Icons Below | |||||||
 |
 |
 |
 |
 |
NO UL,UR |
NO CSA |
RoHS 10/10 |
| SKU | B6A-NH-PCB-RS-NS |
|---|---|
| Number of Wires | 1 Wire |
| Condition | New |
| AWG Wire Range | 6 - 14 AWG |
| FLEX Wire Range | No FLEX Wire |
| Screw Type | No Screw |
| CSA Canadian Standards Association Certified | No |
| UL | Not UL Listed or Recognized |
| Meets RoHS | Yes |
